Posted by I must say this Release Update (RU) was probably the smoothest I’ve ever done. Obviously you should always read the patch notes carefully before proceeding on your own systems, but for me, it was a simple exercise. I’m posting this just to cover a couple of things that the patch notes “assume” and don’t explicitly state.
- Shutdown everything Oracle related. I just go to “Services” and look for anything with Oracle. Also shutdown the “Distributed Transaction Coordinator service”.
This next one is key … I’ve made this mistake so many times. Open a command prompt window as administrator. If you don’t, things will progress OK for a tiny bit and then OPatch is going to throw a wobbly.
I did both the 19.7 RU and the 19.7 OJVM with OPatch, and both went through without incident.
C:\WINDOWS\system32>set PATH=%ORACLE_HOME%\perl\bin;%PATH%
C:\WINDOWS\system32>set PATH=%PATH%;%ORACLE_HOME%\OPatch
C:\WINDOWS\system32>cd D:\oracle\stage\19.7windows\30901317
C:\WINDOWS\system32>d:
D:\oracle\stage\19.7windows\30901317>opatch apply
Oracle Interim Patch Installer version 12.2.0.1.19
Copyright (c) 2020, Oracle Corporation. All rights reserved.
Oracle Home : C:\oracle\product\19
Central Inventory : C:\Program Files\Oracle\Inventory
from :
OPatch version : 12.2.0.1.19
OUI version : 12.2.0.7.0
Log file location : C:\oracle\product\19\cfgtoollogs\opatch\opatch2020-06-05_18-52-57PM_1.log
Verifying environment and performing prerequisite checks...
OPatch continues with these patches: 30901317
Do you want to proceed? [y|n]
y
User Responded with: Y
All checks passed.
Please shutdown Oracle instances running out of this ORACLE_HOME on the local system.
(Oracle Home = 'C:\oracle\product\19')
Is the local system ready for patching? [y|n]
y
User Responded with: Y
Backing up files...
Applying interim patch '30901317' to OH 'C:\oracle\product\19'
ApplySession: Optional component(s)
[ oracle.assistants.usm, 19.0.0.0.0 ] ,
[ oracle.rdbms.ic, 19.0.0.0.0 ] ,
[ oracle.rdbms.tg4ifmx, 19.0.0.0.0 ] ,
[ oracle.has.deconfig, 19.0.0.0.0 ] ,
[ oracle.has.cfs, 19.0.0.0.0 ] ,
[ oracle.rdbms.tg4tera, 19.0.0.0.0 ] ,
[ oracle.network.gsm, 19.0.0.0.0 ] ,
[ oracle.network.cman, 19.0.0.0.0 ] ,
[ oracle.rdbms.tg4msql, 19.0.0.0.0 ] ,
[ oracle.ons.daemon, 19.0.0.0.0 ] ,
[ oracle.options.olap.awm, 19.0.0.0.0 ] ,
[ oracle.swd.oui, 12.2.0.4.0 ] ,
[ oracle.swd.oui.core.min, 12.2.0.4.0 ] ,
[ oracle.rdbms.tg4db2, 19.0.0.0.0 ] ,
[ oracle.assistants.asm, 19.0.0.0.0 ] ,
[ oracle.usm, 19.0.0.0.0 ] ,
[ oracle.tomcat.crs, 19.0.0.0.0 ] ,
[ oracle.has.crs, 19.0.0.0.0 ] ,
[ oracle.tfa, 19.0.0.0.0 ] ,
[ oracle.has.cvu, 19.0.0.0.0 ] ,
[ oracle.rdbms.tg4sybs, 19.0.0.0.0 ] not present in the Oracle Home or a higher version is found.
Patching component oracle.sdo, 19.0.0.0.0...
Patching component oracle.rdbms.rman, 19.0.0.0.0...
Patching component oracle.aspnet_2, 19.0.0.0.0...
Patching component oracle.dbjava.ic, 19.0.0.0.0...
Patching component oracle.ons, 19.0.0.0.0...
Patching component oracle.ntoramts, 19.0.0.0.0...
Patching component oracle.rdbms.dbscripts, 19.0.0.0.0...
Patching component oracle.xdk.parser.java, 19.0.0.0.0...
Patching component oracle.nlsrtl.rsf, 19.0.0.0.0...
Patching component oracle.rdbms, 19.0.0.0.0...
Patching component oracle.blaslapack, 19.0.0.0.0...
Patching component oracle.rdbms.oci, 19.0.0.0.0...
Patching component oracle.assistants.acf, 19.0.0.0.0...
Patching component oracle.duma, 19.0.0.0.0...
Patching component oracle.tfa.db, 19.0.0.0.0...
Patching component oracle.ldap.security.osdt, 19.0.0.0.0...
Patching component oracle.ctx.atg, 19.0.0.0.0...
Patching component oracle.dbjava.jdbc, 19.0.0.0.0...
Patching component oracle.xdk.rsf, 19.0.0.0.0...
Patching component oracle.precomp.common, 19.0.0.0.0...
Patching component oracle.rdbms.hsodbc, 19.0.0.0.0...
Patching component oracle.sqlplus.ic, 19.0.0.0.0...
Patching component oracle.oracore.rsf, 19.0.0.0.0...
Patching component oracle.rsf, 19.0.0.0.0...
Patching component oracle.precomp.common.core, 19.0.0.0.0...
Patching component oracle.network.client, 19.0.0.0.0...
Patching component oracle.precomp.lang, 19.0.0.0.0...
Patching component oracle.install.deinstalltool, 19.0.0.0.0...
Patching component oracle.ctx, 19.0.0.0.0...
Patching component oracle.dbjava.ucp, 19.0.0.0.0...
Patching component oracle.javavm.client, 19.0.0.0.0...
Patching component oracle.network.listener, 19.0.0.0.0...
Patching component oracle.ntoledb.odp_net_2, 19.0.0.0.0...
Patching component oracle.rdbms.util, 19.0.0.0.0...
Patching component oracle.usm.deconfig, 19.0.0.0.0...
Patching component oracle.assistants.server, 19.0.0.0.0...
Patching component oracle.rdbms.deconfig, 19.0.0.0.0...
Patching component oracle.ntoledb, 19.0.0.0.0...
Patching component oracle.has.common, 19.0.0.0.0...
Patching component oracle.assistants.deconfig, 19.0.0.0.0...
Patching component oracle.ldap.rsf, 19.0.0.0.0...
Patching component oracle.ovm, 19.0.0.0.0...
Patching component oracle.rdbms.plsql, 19.0.0.0.0...
Patching component oracle.has.db, 19.0.0.0.0...
Patching component oracle.precomp.rsf, 19.0.0.0.0...
Patching component oracle.xdk, 19.0.0.0.0...
Patching component oracle.sdo.locator, 19.0.0.0.0...
Patching component oracle.rdbms.install.plugins, 19.0.0.0.0...
Patching component oracle.rdbms.olap, 19.0.0.0.0...
Patching component oracle.rdbms.rsf.ic, 19.0.0.0.0...
Patching component oracle.rdbms.scheduler, 19.0.0.0.0...
Patching component oracle.ldap.owm, 19.0.0.0.0...
Patching component oracle.rdbms.rsf, 19.0.0.0.0...
Patching component oracle.network.rsf, 19.0.0.0.0...
Patching component oracle.oraolap, 19.0.0.0.0...
Patching component oracle.clrintg.ode_net_2, 19.0.0.0.0...
Patching component oracle.rdbms.dv, 19.0.0.0.0...
Patching component oracle.has.rsf, 19.0.0.0.0...
Patching component oracle.sqlplus, 19.0.0.0.0...
Patching component oracle.has.common.cvu, 19.0.0.0.0...
Patch 30901317 successfully applied.
Sub-set patch [30445947] has become inactive due to the application of a super-set patch [30901317].
Please refer to Doc ID 2161861.1 for any possible further required actions.
Log file location: C:\oracle\product\19\cfgtoollogs\opatch\opatch2020-06-05_18-52-57PM_1.log
OPatch succeeded.
D:\oracle\stage\19.7windows\30901317>cd ..
D:\oracle\stage\19.7windows>cd jvm
D:\oracle\stage\19.7windows\jvm>cd 30805684
D:\oracle\stage\19.7windows\jvm\30805684>opatch prereq CheckConflictAgainstOHWithDetail -ph .
Oracle Interim Patch Installer version 12.2.0.1.19
Copyright (c) 2020, Oracle Corporation. All rights reserved.
PREREQ session
Oracle Home : C:\oracle\product\19
Central Inventory : C:\Program Files\Oracle\Inventory
from :
OPatch version : 12.2.0.1.19
OUI version : 12.2.0.7.0
Log file location : C:\oracle\product\19\cfgtoollogs\opatch\opatch2020-06-05_18-59-04PM_1.log
Invoking prereq "checkconflictagainstohwithdetail"
Prereq "checkConflictAgainstOHWithDetail" passed.
OPatch succeeded.
D:\oracle\stage\19.7windows\jvm\30805684>
D:\oracle\stage\19.7windows\jvm\30805684>opatch apply
Oracle Interim Patch Installer version 12.2.0.1.19
Copyright (c) 2020, Oracle Corporation. All rights reserved.
Oracle Home : C:\oracle\product\19
Central Inventory : C:\Program Files\Oracle\Inventory
from :
OPatch version : 12.2.0.1.19
OUI version : 12.2.0.7.0
Log file location : C:\oracle\product\19\cfgtoollogs\opatch\opatch2020-06-05_19-12-41PM_1.log
Verifying environment and performing prerequisite checks...
OPatch continues with these patches: 30805684
Do you want to proceed? [y|n]
y
User Responded with: Y
All checks passed.
Please shutdown Oracle instances running out of this ORACLE_HOME on the local system.
(Oracle Home = 'C:\oracle\product\19')
Is the local system ready for patching? [y|n]
y
User Responded with: Y
Backing up files...
Applying interim patch '30805684' to OH 'C:\oracle\product\19'
Patching component oracle.rdbms, 19.0.0.0.0...
Patching component oracle.rdbms.dbscripts, 19.0.0.0.0...
Patching component oracle.javavm.server, 19.0.0.0.0...
Patching component oracle.javavm.client, 19.0.0.0.0...
Patch 30805684 successfully applied.
Log file location: C:\oracle\product\19\cfgtoollogs\opatch\opatch2020-06-05_19-12-41PM_1.log
OPatch succeeded.
D:\oracle\stage\19.7windows\jvm\30805684>
Then its a case of starting the databases in upgrade mode and then running datapatch. This is my only criticism of the Windows setup here. If I just start the services, the database is completely open, and hence needs to be shutdown entirely again so that it can be started in upgrade mode. I tried the old “oradim” command which is meant to allow me to start just the service and not the instance, ie
oradim -startup -sid db19 -starttype srvc
but I found that this also started the entire instance and database. So you might just have to tough it out and accept that its going to need a second shutdown/startup.
SQL> startup upgrade
ORACLE instance started.
Total System Global Area 4294966040 bytes
Fixed Size 9276184 bytes
Variable Size 2113929216 bytes
Database Buffers 2164260864 bytes
Redo Buffers 7499776 bytes
Database mounted.
Database opened.
SQL> alter pluggable database all open upgrade;
Pluggable database altered.
C:\oracle\product\19\OPatch>datapatch -verbose
SQL Patching tool version 19.3.0.0.0 Production on Fri Jun 5 19:25:22 2020
Copyright (c) 2012, 2019, Oracle. All rights reserved.
Log file for this invocation: C:\oracle\cfgtoollogs\sqlpatch\sqlpatch_44888_2020_06_05_19_25_22\sqlpatch_invocation.log
Connecting to database...OK
Gathering database info...done
Note: Datapatch will only apply or rollback SQL fixes for PDBs
that are in an open state, no patches will be applied to closed PDBs.
Please refer to Note: Datapatch: Database 12c Post Patch SQL Automation
(Doc ID 1585822.1)
Bootstrapping registry and package to current versions...done
Determining current state...done
Current state of interim SQL patches:
Interim patch 30805684 (OJVM RELEASE UPDATE: 19.7.0.0.200414 (30805684)):
Binary registry: Installed
PDB CDB$ROOT: Not installed
PDB PDB$SEED: Not installed
PDB PDB1: Not installed
PDB PDB2: Not installed
Current state of release update SQL patches:
Binary registry:
19.7.0.0.0 Release_Update 200514113449: Installed
PDB CDB$ROOT:
Applied 19.6.0.0.0 Release_Update 200104221455 successfully on 20-MAR-20 07.53.55.650000 PM
PDB PDB$SEED:
Applied 19.6.0.0.0 Release_Update 200104221455 successfully on 20-MAR-20 07.53.57.153000 PM
PDB PDB1:
Applied 19.6.0.0.0 Release_Update 200104221455 successfully on 20-MAR-20 07.53.57.351000 PM
PDB PDB2:
Applied 19.6.0.0.0 Release_Update 200104221455 successfully on 20-MAR-20 07.53.57.153000 PM
Adding patches to installation queue and performing prereq checks...done
Installation queue:
For the following PDBs: CDB$ROOT PDB$SEED PDB1 PDB2
No interim patches need to be rolled back
Patch 30901317 (Windows Database Bundle Patch : 19.7.0.0.200414 (30901317)):
Apply from 19.6.0.0.0 Release_Update 200104221455 to 19.7.0.0.0 Release_Update 200514113449
The following interim patches will be applied:
30805684 (OJVM RELEASE UPDATE: 19.7.0.0.200414 (30805684))
Installing patches...
Patch installation complete. Total patches installed: 8
Validating logfiles...done
Patch 30901317 apply (pdb CDB$ROOT): SUCCESS
logfile: C:\oracle\cfgtoollogs\sqlpatch\30901317\23471163/30901317_apply_DB19_CDBROOT_2020Jun05_19_27_50.log (no errors)
Patch 30805684 apply (pdb CDB$ROOT): SUCCESS
logfile: C:\oracle\cfgtoollogs\sqlpatch\30805684\23504850/30805684_apply_DB19_CDBROOT_2020Jun05_19_27_15.log (no errors)
Patch 30901317 apply (pdb PDB$SEED): SUCCESS
logfile: C:\oracle\cfgtoollogs\sqlpatch\30901317\23471163/30901317_apply_DB19_PDBSEED_2020Jun05_19_28_42.log (no errors)
Patch 30805684 apply (pdb PDB$SEED): SUCCESS
logfile: C:\oracle\cfgtoollogs\sqlpatch\30805684\23504850/30805684_apply_DB19_PDBSEED_2020Jun05_19_28_34.log (no errors)
Patch 30901317 apply (pdb PDB1): SUCCESS
logfile: C:\oracle\cfgtoollogs\sqlpatch\30901317\23471163/30901317_apply_DB19_PDB1_2020Jun05_19_28_41.log (no errors)
Patch 30805684 apply (pdb PDB1): SUCCESS
logfile: C:\oracle\cfgtoollogs\sqlpatch\30805684\23504850/30805684_apply_DB19_PDB1_2020Jun05_19_28_34.log (no errors)
Patch 30901317 apply (pdb PDB2): SUCCESS
logfile: C:\oracle\cfgtoollogs\sqlpatch\30901317\23471163/30901317_apply_DB19_PDB2_2020Jun05_19_28_41.log (no errors)
Patch 30805684 apply (pdb PDB2): SUCCESS
logfile: C:\oracle\cfgtoollogs\sqlpatch\30805684\23504850/30805684_apply_DB19_PDB2_2020Jun05_19_28_34.log (no errors)
Automatic recompilation incomplete; run utlrp.sql to revalidate.
PDBs: CDB$ROOT
SQL Patching tool complete on Fri Jun 5 19:30:10 2020
C:\oracle\product\19\OPatch>
C:\oracle\product\19\OPatch>sqlplus / as sysdba
SQL*Plus: Release 19.0.0.0.0 - Production on Fri Jun 5 19:33:16 2020
Version 19.7.0.0.0
Copyright (c) 1982, 2020, Oracle. All rights reserved.
Connected to:
Oracle Database 19c Enterprise Edition Release 19.0.0.0.0 - Production
Version 19.7.0.0.0
SQL> shutdown immediate
Database closed.
Database dismounted.
ORACLE instance shut down.
SQL> startup
ORACLE instance started.
Total System Global Area 4294966040 bytes
Fixed Size 9276184 bytes
Variable Size 2113929216 bytes
Database Buffers 2164260864 bytes
Redo Buffers 7499776 bytes
Database mounted.
Database opened.
SQL>
One thing to be aware of once your patching is completed (and your experiences may be different) is that because the act of patching resulted in a growth of my SYSTEM, UNDO and SYSAUX tablespaces, the database engine seemed to think that it was in the middle of a large space growth activity. As a result, my space management slaves went absolutely bonkers for 2-3mins once I re-opened the database. So I’d recommend you patch in a quiet time just in case you are also impacted. (It is mostly likely because I run my databases very lean on space because I have so many of them … I suspect a well managed database is unlikely to encounter this
)
SQL> @active_sess
SID SERIAL# USERNAME_SECONDS_ACTIVE STATUS SQL_ID PROGRAM
---------- ---------- --------------------------------------------- -------- ------------- -----------------
5 2450 SYS (260) ACTIVE ORACLE.EXE (W008)
7 23944 SYS (236) ACTIVE ORACLE.EXE (W00G)
127 61619 SYS (257) ACTIVE ORACLE.EXE (W009)
130 38485 SYS (233) ACTIVE ORACLE.EXE (W00H)
254 33664 SYS (230) ACTIVE ORACLE.EXE (W00I)
369 43820 SYS (0) ACTIVE gg5tyt1pvnr47 sqlplus.exe
372 21722 SYS (254) ACTIVE ORACLE.EXE (W00A)
374 46323 SYS (227) ACTIVE ORACLE.EXE (W00J)
495 4987 SYS (224) ACTIVE ORACLE.EXE (W00K)
616 1532 SYS (251) ACTIVE ORACLE.EXE (W00B)
619 63318 SYS (221) ACTIVE ORACLE.EXE (W00L)
739 43427 SYS (218) ACTIVE ORACLE.EXE (W00M)
860 11487 SYS (215) ACTIVE ORACLE.EXE (W00N)
982 7708 SYS (248) ACTIVE ORACLE.EXE (W00C)
1106 52591 SYS (245) ACTIVE ORACLE.EXE (W00D)
1227 15812 SYS (242) ACTIVE ORACLE.EXE (W00E)
1347 39327 SYS (263) ACTIVE ORACLE.EXE (W007)
1349 15601 SYS (239) ACTIVE ORACLE.EXE (W00F)
As part of this exercise I found an awesome MOS note, which covers exactly what is fixed in each RU. Be sure to visit MOS note 2523220.1 for all the details. I am not permitted to cut/paste it here, but the image below gives you a flavour of the contents…You get each major section of the database, the bugs fixed in each RU, plus hyperlinks to the bug description. Very cool as a quick reference for seeing if a bug you are being impacted by is fixed in a particular RU.
Happy patching everyone!
Addenda June 17 2019:
There’s some internal discussion about whether the “upgrade” option is required for the “alter pluggable all open” command before the data patching. Some good information on that here https://mikedietrichde.com/2020/01/23/do-you-need-startup-upgrade-for-ojvm/.
Thanks to Daniel Overby Hansen for bringing this to my attention.
Learning is not a spectator sport
Hello Connor, Thanks for sharing!
Any reason why you did not use the “New AutoUpgrade”?
I have not use the “New AutoUpgrade”, still doing my upgrades the old fashion way
Regards,
jorge
Solely because I’m a dinosaur 🙂 But I’ve done some 18 to 19 upgrades with autoupgrade and it was smooth as silk. The upgrade guys have done a fantastic job with that tool
did you run utlrp.sql?
Automatic recompilation incomplete; run utlrp.sql to revalidate.
PDBs: CDB$ROOT
