Text indexes for numbers

Connor McDonald , , , ,

We had an AskTOM question recently about being able to search for numbers within a concatenated list. The particular issue was a list of mobile phone numbers, but this is really just about tackling the larger issue of finding numbers within list.

Let’s create a simple example to see where things can break down (and how we can fix them).


SQL> create table t (  cid int, mobs varchar2(1000));

Table created.

SQL>
SQL> insert into t
  2  select c, listagg(num,',') within group ( order by num )
  3  from
  4  ( select mod(rownum,1000) c, trunc(dbms_random.value(1000000,9999999)) num from dual connect by level <= 4000 )
  5  group by c;

1000 rows created.

SQL>
SQL> exec dbms_stats.gather_table_stats('','T');

PL/SQL procedure successfully completed.

SQL>
SQL> select * from t
  2  where rownum <= 10;

       CID MOBS
---------- --------------------------------------------------
         0 2644307,3565512,5481105,7725189
         1 1570287,2092729,6127058,6546683
         2 6018800,6408347,6592531,8456137
         3 2087673,3086382,6692756,9377699
         4 2964558,3887606,6305557,7441515
         5 2219544,4331436,5246494,5303583
         6 1005450,1625403,2271986,4493049
         7 2605217,5143371,7444316,9073658
         8 1205487,4660509,5148296,9578099
         9 3736741,8385346,8758352,9496363

10 rows selected.

My sample table has 1000 rows and there a four “mobile phone” numbers concatenated into a list for each row.

(Side note: I’m not using 555-prefixed numbers like you’ll see in the movies Smile Why phone numbers in movies start with 555)

Now let us try query the table for one of the phone numbers as highlighted in red in the previous list.


SQL>
SQL> select * from t where mobs like '%7444316%';

       CID MOBS
---------- ----------------------------------------
         7 2605217,5143371,7444316,9073658

1 row selected.

SQL> set autotrace traceonly explain
SQL> select * from t where mobs like '%7444316%';

Execution Plan
----------------------------------------------------------
Plan hash value: 1601196873

--------------------------------------------------------------------------
| Id  | Operation         | Name | Rows  | Bytes | Cost (%CPU)| Time     |
--------------------------------------------------------------------------
|   0 | SELECT STATEMENT  |      |    50 |  1800 |     5   (0)| 00:00:01 |
|*  1 |  TABLE ACCESS FULL| T    |    50 |  1800 |     5   (0)| 00:00:01 |
--------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   1 - filter("MOBS" LIKE '%7444316%' AND "MOBS" IS NOT NULL)

I got the correct row back from the query, but the full scan of the table might be an issue as this table grows to larger sizes. (I’m working on the assumption here that a search for a single number will never return a large number of rows).

Since this is a “term that could be anywhere within the string” style of search, creating a Text index on the column seems an obvious choice. So I’ll do that and try again:


SQL> set autotrace off
SQL>
SQL> create index ix on t ( mobs ) indextype is ctxsys.context;

Index created.

SQL>
SQL> set autotrace traceonly explain
SQL> select * from t where contains(mobs,'7444316') > 0;

Execution Plan
----------------------------------------------------------
Plan hash value: 1339481741

------------------------------------------------------------------------------------
| Id  | Operation                   | Name | Rows  | Bytes | Cost (%CPU)| Time     |
------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT            |      |     1 |    36 |     4   (0)| 00:00:01 |
|   1 |  TABLE ACCESS BY INDEX ROWID| T    |     1 |    36 |     4   (0)| 00:00:01 |
|*  2 |   DOMAIN INDEX              | IX   |       |       |     4   (0)| 00:00:01 |
------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   2 - access("CTXSYS"."CONTAINS"("MOBS",'7444316')>0)

That is looking a lot better. I’ll be able to take advantage of this index….or so it might first appear! (Cue ominous sounding music…)

There is an ever so slight problem here – we don’t get the rows we need!


SQL> set autotrace off
SQL> select * from t where contains(mobs,'7444316') > 0;

no rows selected

In fact, even if we concocted a search for the value of the entire column, we still do not get a result back from our query.



SQL> select * from t where contains(mobs,'2605217,5143371,7444316,9073658') > 0;

no rows selected

You need to careful with indexing terms that are not what could be thought of as “common” text. After all, it is a Text index, and by default, the assumption here is that we are indexing document style text.

But the solution is easy – we just need to manipulate the standard lexer to avoid common numeric separators (comma, period, etc) perturbing our index entries. I’m opting for a tilde (~) here because it does not appear in the source column.



SQL>
SQL> drop index ix;

Index dropped.

SQL> begin
  2        ctx_ddl.drop_preference('my_lexer');
  3        ctx_ddl.create_preference('my_lexer', 'BASIC_LEXER');
  4        ctx_ddl.set_attribute('my_lexer', 'numgroup', '~');
  5  end;
  6  /

PL/SQL procedure successfully completed.

SQL>
SQL> create index ix on t ( mobs ) indextype is ctxsys.context PARAMETERS('lexer my_lexer');

Index created.

SQL>
SQL> set autotrace traceonly explain
SQL> select * from t
  2  where contains(mobs,'7444316') > 0;

Execution Plan
----------------------------------------------------------
Plan hash value: 1339481741

------------------------------------------------------------------------------------
| Id  | Operation                   | Name | Rows  | Bytes | Cost (%CPU)| Time     |
------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT            |      |     1 |    36 |     4   (0)| 00:00:01 |
|   1 |  TABLE ACCESS BY INDEX ROWID| T    |     1 |    36 |     4   (0)| 00:00:01 |
|*  2 |   DOMAIN INDEX              | IX   |       |       |     4   (0)| 00:00:01 |
------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   2 - access("CTXSYS"."CONTAINS"("MOBS",'7444316')>0)

SQL>
SQL> set autotrace off
SQL> select * from t
  2  where contains(mobs,'7444316') > 0;

       CID MOBS
---------- --------------------------------------------------
         7 2605217,5143371,7444316,9073658

1 row selected.

Our execution plan still shows that we can take advantage of the Text index, but I’m also getting the results I expected.

As an aside, Text indexes are one of those gems in the Oracle database that often gets a great amount of new functionality with each new release. So every time you upgrade, take a fresh look at the Text Index documentation. You might get a lot of cool ideas for how to use them in your applications.

Cool stuff with partition elimination

Connor McDonald , , ,

Sometimes in the IT world, the term “surprise” is not a good one.

“I woke up this morning and got a surprise…my database was down.”

“I ran a SELECT COUNT(*) on my most important table, and got a surprise result of zero rows.”

and so forth. Generally as IT professionals, encountering the unexpected is not a good start to the day Smile.

But sometimes, surprises can be a nice thing.  Here is my example for today – when I found that the database can do a remarkably good job when it comes to reducing the workload with partitioned tables.

Most people will already be familiar with the concept of partition elimination.  If you have a table partitioned into (say) yearly segments, and you ask for all of the data for the past 2 years, then the optimizer is intelligent enough to only scan the relevant partitions rather than the entire table.  Here is an example of that in action. I have a table that is partitioned by year on a END_DATE column, and then sub-partitioned into quarters based on a START_DATE column.


SQL> create table t
  2      partition by range( end_dt )
  3      subpartition by range( start_dt )
  4      (
  5         partition p_2014 values less than ( to_date('01-Jan-2015','dd-mon-yyyy') )
  6                 (
  7                         subpartition sp_2014_q1 values less than ( to_date('01-apr-2014','dd-mon-yyyy') ) ,
  8                         subpartition sp_2014_q2 values less than ( to_date('01-jul-2014','dd-mon-yyyy') ) ,
  9                         subpartition sp_2014_q3 values less than ( to_date('01-oct-2014','dd-mon-yyyy') ) ,
 10                         subpartition sp_2014_q4 values less than ( to_date('01-jan-2015','dd-mon-yyyy') )
 11                ) ,
 12        partition p_2015 values less than ( to_date('01-Jan-2016','dd-mon-yyyy') )
 13                (
 14                        subpartition sp_2015_q1 values less than ( to_date('01-apr-2015','dd-mon-yyyy') ) ,
 15                        subpartition sp_2015_q2 values less than ( to_date('01-jul-2015','dd-mon-yyyy') ) ,
 16                        subpartition sp_2015_q3 values less than ( to_date('01-oct-2015','dd-mon-yyyy') ) ,
 17                        subpartition sp_2015_q4 values less than ( to_date('01-jan-2016','dd-mon-yyyy') )
 18                )
 19     )
 20     as
 21     select a.* ,
 22        to_date('01-Jan-2014','dd-mon-yyyy') + mod(rownum,730)-1 as start_dt,
 23        to_date('01-Jan-2014','dd-mon-yyyy') + mod(rownum,730) as end_dt
 24     from all_objects a;

Table created.

SQL>
SQL> alter table t modify start_dt not null;

Table altered.

SQL> alter table t modify end_dt not null;

Table altered.

SQL>
SQL> set autotrace traceonly explain
SQL> select *
  2      from t
  3      where start_dt = to_date('13-Jan-2015','dd-mon-yyyy') ;

Execution Plan
----------------------------------------------------------
Plan hash value: 2183203583

------------------------------------------------------------------------------------------------
| Id  | Operation               | Name | Rows  | Bytes | Cost (%CPU)| Time     | Pstart| Pstop |
------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT        |      |   101 | 15049 |   491   (1)| 00:00:01 |       |       |
|   1 |  PARTITION RANGE ALL    |      |   101 | 15049 |   491   (1)| 00:00:01 |     1 |     2 |
|   2 |   PARTITION RANGE SINGLE|      |   101 | 15049 |   491   (1)| 00:00:01 |       |       |
|*  3 |    TABLE ACCESS FULL    | T    |   101 | 15049 |   491   (1)| 00:00:01 |       |       |
------------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - filter("START_DT"=TO_DATE(' 2015-01-13 00:00:00', 'syyyy-mm-dd hh24:mi:ss'))

You can see that we had to scan all of the partitions, but within each of the partitions we only had to scan a single sub-partition (as indicated by “PARTITION RANGE SINGLE”).  So for each year (based on END_DT) we scanned a single one of the 4 subpartitions.  We are doing only 25% of the work of scanning the entire table.  But one pleasant surprise I saw today was how the optimizer can take advantage of additional information to improve things even more.  Let us now add a fairly obvious rule about the data:


SQL>
SQL> alter table t add constraint t_chk check( start_dt < end_dt );

Table altered.

And have another look at that query execution plan.


SQL>
SQL> set autotrace traceonly explain
SQL> select *
  2      from t
  3      where start_dt = to_date('13-Jan-2015','dd-mon-yyyy') ;

Execution Plan
----------------------------------------------------------
Plan hash value: 3874588989

------------------------------------------------------------------------------------------------
| Id  | Operation               | Name | Rows  | Bytes | Cost (%CPU)| Time     | Pstart| Pstop |
------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT        |      |   101 | 15049 |   247   (1)| 00:00:01 |       |       |
|   1 |  PARTITION RANGE SINGLE |      |   101 | 15049 |   247   (1)| 00:00:01 |     2 |     2 |
|   2 |   PARTITION RANGE SINGLE|      |   101 | 15049 |   247   (1)| 00:00:01 |     1 |     1 |
|*  3 |    TABLE ACCESS FULL    | T    |   101 | 15049 |   247   (1)| 00:00:01 |     5 |     5 |
------------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - filter("START_DT"=TO_DATE(' 2015-01-13 00:00:00', 'syyyy-mm-dd hh24:mi:ss') AND
              "END_DT">TO_DATE(' 2015-01-13 00:00:00', 'syyyy-mm-dd hh24:mi:ss'))

SQL>
SQL>

How cool is that!  The constraint let us remove even more partitions from consideration. In fact, we ended up only scanning a single partition. Moreover, we never specified END_DT as a predicate, but you can see in the FILTER section, we could synthesize such a predicate using the rule defined by the check constraint we added.

I suppose the moral of the story is two-fold here.

1) The optimizer can be pretty smart with partition elimination,

2) As always, never hide rules and facts about the data from the database.  Make sure you define those constraints in the database tier.

NVL vs COALESCE

Connor McDonald , , ,

Jonathan Lewis just published a blog post about NVL and COALESCE and the optimizer costings for each.

There is also perhaps a significant difference between NVL and COALESCE in that the former seems to have an in-built optimization for handling bind variables and nulls.

Consider an application where users optionally pass in search criteria and you have to query a table based on that criteria.  You have three natural choices here to implement that:

WHERE column = :search_criteria or :search_criteria is null

or

WHERE column = nvl(:search_criteria ,column)

or

WHERE column = coalesce(:search_criteria,column)

Functionally they are identical*, but the implementation detail shows a nice little optimizer trick that only works with NVL.


SQL> create table t as select * From dba_objects;

Table created.

SQL> variable search_criteria number
SQL>
SQL> exec :search_criteria := 123

PL/SQL procedure successfully completed.

SQL>
SQL> create index ix1 on t ( object_id ) ;

Index created.

SQL>
SQL> set feedback only
SQL> select *
  2  from t
  3  where object_id = nvl(:search_criteria,object_id);

1 row selected.

SQL>
SQL> set feedback on
SQL> select * from dbms_xplan.display_cursor();

PLAN_TABLE_OUTPUT
-----------------------------------------------------------------------------------------------------------
SQL_ID  0g820t1jw00hm, child number 0
-------------------------------------
select * from t where object_id = nvl(:search_criteria,object_id)

Plan hash value: 2258578794

----------------------------------------------------------------------------------------------------------
| Id  | Operation                              | Name            | Rows  | Bytes | Cost (%CPU)| Time     |
----------------------------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT                       |                 |       |       |   430 (100)|          |
|   1 |  VIEW                                  | VW_ORE_1B35BA0F | 78868 |    36M|   430   (1)| 00:00:01 |
|   2 |   UNION-ALL                            |                 |       |       |            |          |
|*  3 |    FILTER                              |                 |       |       |            |          |
|   4 |     TABLE ACCESS BY INDEX ROWID BATCHED| T               |     1 |   132 |     2   (0)| 00:00:01 |
|*  5 |      INDEX RANGE SCAN                  | IX1             |     1 |       |     1   (0)| 00:00:01 |
|*  6 |    FILTER                              |                 |       |       |            |          |
|*  7 |     TABLE ACCESS FULL                  | T               | 78867 |     9M|   428   (1)| 00:00:01 |
----------------------------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   3 - filter(:SEARCH_CRITERIA IS NOT NULL)
   5 - access("OBJECT_ID"=:SEARCH_CRITERIA)
   6 - filter(:SEARCH_CRITERIA IS NULL)
   7 - filter("OBJECT_ID" IS NOT NULL)


27 rows selected.

SQL>
SQL> set feedback only
SQL> select *
  2  from t
  3  where object_id = coalesce(:search_criteria,object_id);

1 row selected.

SQL>
SQL> set feedback on
SQL> select * from dbms_xplan.display_cursor();

PLAN_TABLE_OUTPUT
-----------------------------------------------------------------------------------------------------------
SQL_ID  am3uvm7nvx5d9, child number 0
-------------------------------------
select * from t where object_id = coalesce(:search_criteria,object_id)

Plan hash value: 1601196873

--------------------------------------------------------------------------
| Id  | Operation         | Name | Rows  | Bytes | Cost (%CPU)| Time     |
--------------------------------------------------------------------------
|   0 | SELECT STATEMENT  |      |       |       |   427 (100)|          |
|*  1 |  TABLE ACCESS FULL| T    |     1 |   132 |   427   (1)| 00:00:01 |
--------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   1 - filter("OBJECT_ID"=COALESCE(:SEARCH_CRITERIA,"OBJECT_ID"))


18 rows selected.

SQL>
SQL>
SQL>
SQL> set feedback only
SQL> select *
  2  from t
  3  where ( object_id = :search_criteria or :search_criteria is null );

1 row selected.

SQL>
SQL> set feedback on
SQL> select * from dbms_xplan.display_cursor();

PLAN_TABLE_OUTPUT
-----------------------------------------------------------------------------------------------------------
SQL_ID  ff0s2j51scxss, child number 0
-------------------------------------
select * from t where ( object_id = :search_criteria or
:search_criteria is null )

Plan hash value: 1601196873

--------------------------------------------------------------------------
| Id  | Operation         | Name | Rows  | Bytes | Cost (%CPU)| Time     |
--------------------------------------------------------------------------
|   0 | SELECT STATEMENT  |      |       |       |   427 (100)|          |
|*  1 |  TABLE ACCESS FULL| T    |  3945 |   508K|   427   (1)| 00:00:01 |
--------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   1 - filter((:SEARCH_CRITERIA IS NULL OR
              "OBJECT_ID"=:SEARCH_CRITERIA))


20 rows selected.

SQL>

Only NVL gets the benefit of the query being “split” into two pieces – one to handle the case where the passed criteria is null, and the other for when the criteria is not null.  The FILTER in line 3 shows that we will only run one or the other.

So for these particular types of queries, make sure you test all the possibilities – you might find NVL (currently) is your best bet.



* – Addenda:  Thanks to Jonathan for pointing out that you can get discrepancies in the results for the three strategies above for columns that may contain nulls, so as always, take care.

NULL’s vs NOT NULL’s and Performance

Connor McDonald , , , ,

When it comes to giving the cost based optimiser the best possible chance to make the “right” decisions, many DBA’s are diligent in keeping statistics up to date, using histograms where appropriate, creating more indexes (or removing surplus indexes).

However one often neglected area is that the the null-ness of columns also impacts the optimiser decisions. NULL and NOT NULL do more than just act as constraints, they also add (or detract) to the value of indexes on those columns. Here’s an example of how the null-ness of a column impacts optimizer decisions. I have a table T which is a copy of DBA_OBJECTS, indexed on OBJECT_ID.


SQL> create table t as
  2  select * from dba_objects
  3  where object_id is not null;

Table created.

SQL>
SQL> create index IX on T ( object_id );

Index created.

Now I want to perform a standard pagination style query, namely, get the first 5 rows in order of OBJECT_ID


SQL>
SQL> set autotrace traceonly
SQL> select *
  2  from
  3    ( select * from t
  4      order by object_id
  5    )
  6  where rownum <= 5;

5 rows selected.

Execution Plan
----------------------------------------------------------
Plan hash value: 3299198703

----------------------------------------------------------------------------------------
| Id  | Operation               | Name | Rows  | Bytes |TempSpc| Cost (%CPU)| Time     |
----------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT        |      |     5 |  2405 |       |  2755   (1)| 00:00:01 |
|*  1 |  COUNT STOPKEY          |      |       |       |       |            |          |
|   2 |   VIEW                  |      | 78750 |    36M|       |  2755   (1)| 00:00:01 |
|*  3 |    SORT ORDER BY STOPKEY|      | 78750 |     9M|    14M|  2755   (1)| 00:00:01 |
|   4 |     TABLE ACCESS FULL   | T    | 78750 |     9M|       |   428   (1)| 00:00:01 |
----------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   1 - filter(ROWNUM<=5)
   3 - filter(ROWNUM<=5)


Statistics
----------------------------------------------------------
         52  recursive calls
        130  db block gets
       1591  consistent gets
          0  physical reads
      25420  redo size
       2735  bytes sent via SQL*Net to client
        607  bytes received via SQL*Net from client
          2  SQL*Net roundtrips to/from client
          1  sorts (memory)
          0  sorts (disk)
          5  rows processed

I scanned the entire table and burned around 1500 consistent gets. Now I’ll let the database know what I already know, that is, that the OBJECT_ID column is contains no nulls. Then I’ll repeat the same query.


SQL>
SQL> alter table T modify object_id not null;

Table altered.

SQL>
SQL> select *
  2  from
  3    ( select * from t
  4      order by object_id
  5    )
  6  where rownum <= 5;

5 rows selected.

Execution Plan
----------------------------------------------------------
Plan hash value: 3114946973

--------------------------------------------------------------------------------------
| Id  | Operation                     | Name | Rows  | Bytes | Cost (%CPU)| Time     |
--------------------------------------------------------------------------------------
|   0 | SELECT STATEMENT              |      |     5 |  2405 |     3   (0)| 00:00:01 |
|*  1 |  COUNT STOPKEY                |      |       |       |            |          |
|   2 |   VIEW                        |      |     5 |  2405 |     3   (0)| 00:00:01 |
|   3 |    TABLE ACCESS BY INDEX ROWID| T    | 78750 |     9M|     3   (0)| 00:00:01 |
|   4 |     INDEX FULL SCAN           | IX   |     5 |       |     2   (0)| 00:00:01 |
--------------------------------------------------------------------------------------

Predicate Information (identified by operation id):
---------------------------------------------------

   1 - filter(ROWNUM<=5)


Statistics
----------------------------------------------------------
         85  recursive calls
        132  db block gets
         72  consistent gets
          1  physical reads
      27192  redo size
       2735  bytes sent via SQL*Net to client
        607  bytes received via SQL*Net from client
          2  SQL*Net roundtrips to/from client
          2  sorts (memory)
          0  sorts (disk)
          5  rows processed

Woo hoo! 20 times more efficient. The extra information we provided to the database allowed for more execution paths to be considered by the optimizer.

That’s all well and good. By how do we know which columns might be missing an appropriate NOT NULL constraint ?

Well, the following routine might help Smile

The PL/SQL procedure below deduces a ‘number of rows that are null’ count for all columns that are indexed for all tables in the schema (passed as parameter P_SCHEMA), although you can pass a table name to restrict the procedure to just that table. For any column that contains no nulls, the appropriate ‘alter table … ( column_name not null)’ command will be outputted. (Make sure you set serveroutput on).

Notes:

  • The client for whom I wrote this script, had no NOT NULL constraints on any table so the procedure only takes a rough stab at ALL_CONSTRAINTS for existing constraints.
  • It tries to keep things sensible – avoiding complex data types, tables that are auto-generated or used for queues etc, but there’s no guarantee it won’t either miss a table, or pick up it should not.
  • This is a brute force approach – it works by scanning every table in the schema, so use your discretion as to when would be a suitable time for running this routine.  But it will only scan each table once to determine the null count for all candidate columns.
  • (As with any diagnosis script), you should not apply it’s recommendations without some careful thought first.

12.2 version


create or replace
procedure check_indexed_columns_for_null(
                 p_schema varchar2,
                 p_table_name varchar2 default null) is
  cursor x is
   select
     table_name,
     column_name,
     count(*) over ( partition by table_name ) as colcount
     from
     (
       select
         table_name,
         column_name,
         min(existing_constraint)
       from
       (
       select
           a.table_name,
           a.column_name,
           ( select  count(*)
             from    all_constraints x,
                     all_cons_columns cc
             where   x.owner = c.owner
             and     x.table_name = c.table_name
             and     cc.owner      = x.owner
             and     cc.constraint_name = x.constraint_name
             and
            (
               ( x.constraint_type = 'C'  and replace(search_condition_vc,'"') = a.column_name||' IS NOT NULL' )
                   or
               ( x.constraint_type = 'P'  and cc.column_name = a.column_name )
             )
            ) existing_constraint
       from
         all_ind_columns a,
         all_tables c,
         all_tab_columns ccol
       where a.index_owner = p_schema
       and a.index_owner = p_schema
       and a.table_name = nvl(upper(p_table_name),a.table_name)
       and c.table_name = a.table_name
       and c.owner      = a.table_owner
       and c.owner      = ccol.owner
       and c.table_name = ccol.table_name
       and a.column_name = ccol.column_name
       and c.secondary = 'N'
       and c.temporary = 'N'
       and c.nested    = 'NO'
       and c.external  = 'NO'
       and ccol.data_type_owner is null
       and ccol.data_type not in ('LONG','LONG RAW','CLOB','UROWID','UNDEFINED','NCLOB','BLOB','BFILE','ROWID')
       and (c.owner,c.table_name) not in ( select owner, queue_table from all_queue_tables where owner = p_schema )
       )
       group by
         table_name,
         column_name
       having min(existing_constraint) = 0
     );

  str0 varchar2(32767);
  str1 varchar2(32767);
  str2 varchar2(32767);
  str3 varchar2(32767);

  prev varchar2(100) := '*';
  cnt number;
  trailer varchar2(5);

procedure do_sql(thesql varchar2) is
  tcursor integer;
  dummy integer;
begin
  -- dbms_output.put_line(thesql);
  execute immediate thesql;
end;

begin
for i in x loop
  if prev != i.table_name then
    str0 := 'declare ';
    str1 := 'begin select '; str2 := ' into ';
    str3 := ' '; cnt := 1;
  end if;
  if cnt = i.colcount then
    trailer := ' ';
  else
    trailer := ','||chr(10);
  end if;
  str0 := str0 || 'v'||ltrim(cnt)||' number;';
  str1 := str1 || 'sum(decode('||i.column_name||',null,1,0))'||trailer;
  str2 := str2 || 'v'||ltrim(cnt)||trailer;
  str3 := str3 || 'if v'||ltrim(cnt)||' = 0 then '||
    'dbms_output.put_line(''alter table '||p_schema||'.'||i.table_name||
    ' modify ('||i.column_name||' not null);''); end if;'||chr(10);
  if cnt = i.colcount then
    str2 := str2 ||' from '||p_schema||'.'||i.table_name||';';
    str3 := str3 ||' end;';
    do_sql(str0||' '||str1||' '||str2||' '||str3);
  end if;
  prev := i.table_name;
  cnt := cnt + 1;
end loop;
end;
/
sho err

set serverout on
exec check_indexed_columns_for_null('SCOTT')

11.2 version

(Needs a direct CREATE TABLE grant to the owner of the procedure)


create or replace
procedure check_indexed_columns_for_null(
                 p_schema varchar2,
                 p_table_name varchar2 default null) is
  cursor c_template is
    select table_name, column_name, 0 colcount
    from   all_tab_columns;

  type rowlist is table of c_template%rowtype;
  r    rowlist;
  rc   sys_refcursor;

  str0 varchar2(32767);
  str1 varchar2(32767);
  str2 varchar2(32767);
  str3 varchar2(32767);

  prev varchar2(100) := '*';
  cnt number;
  trailer varchar2(5);

procedure do_sql(thesql varchar2) is
  tcursor integer;
  dummy integer;
begin
  dbms_output.put_line(thesql);
  execute immediate thesql;
end;

begin

  begin
    execute immediate 'drop table tmp$cons purge';
  exception when others then null;
  end;

  execute immediate 'create table tmp$cons as  select owner, table_name, constraint_name, constraint_type, to_lob(search_condition) search_condition_vc '||
                    'from all_constraints';

  open rc for
    q'{select
      table_name,
      column_name,
      count(*) over ( partition by table_name ) as colcount
      from
      (
        select
          table_name,
          column_name,
          min(existing_constraint)
        from
        (
        select
            a.table_name,
            a.column_name,
            ( select  count(*)
              from    ( select owner, table_name, constraint_name, constraint_type, cast(search_condition_vc as varchar2(4000)) search_condition_vc
                        from tmp$cons ) x,
                      all_cons_columns cc
              where   x.owner = c.owner
              and     x.table_name = c.table_name
              and     cc.owner      = x.owner
              and     cc.constraint_name = x.constraint_name
              and
             (
                ( x.constraint_type = 'C'  and replace(search_condition_vc,'"') = a.column_name||' IS NOT NULL' )
                    or
                ( x.constraint_type = 'P'  and cc.column_name = a.column_name )
              )
             ) existing_constraint
        from
          all_ind_columns a,
          all_tables c,
          all_tab_columns ccol
        where a.index_owner = :p_schema
        and a.index_owner = :p_schema
        and a.table_name = nvl(upper(:p_table_name),a.table_name)
        and c.table_name = a.table_name
        and c.owner      = a.table_owner
        and c.owner      = ccol.owner
        and c.table_name = ccol.table_name
        and a.column_name = ccol.column_name
        and c.secondary = 'N'
        and c.temporary = 'N'
        and c.nested    = 'NO'
        and (c.owner,c.table_name) not in ( select owner, table_name from all_external_tables where owner = :p_schema )
        and ccol.data_type_owner is null
        and ccol.data_type not in ('LONG','LONG RAW','CLOB','UROWID','UNDEFINED','NCLOB','BLOB','BFILE','ROWID')
        and (c.owner,c.table_name) not in ( select owner, queue_table from all_queue_tables where owner = :p_schema )
        )
        group by
          table_name,
          column_name
        having min(existing_constraint) = 0
      )
      }' using p_schema,p_schema,p_table_name,p_schema,p_schema;

  fetch rc bulk collect into r;
  close rc;

  for i in 1 .. r.count loop
    if prev != r(i).table_name then
      str0 := 'declare ';
      str1 := 'begin select '; str2 := ' into ';
      str3 := ' '; cnt := 1;
    end if;
    if cnt = r(i).colcount then
      trailer := ' ';
    else
      trailer := ','||chr(10);
    end if;
    str0 := str0 || 'v'||ltrim(cnt)||' number;';
    str1 := str1 || 'sum(decode('||r(i).column_name||',null,1,0))'||trailer;
    str2 := str2 || 'v'||ltrim(cnt)||trailer;
    str3 := str3 || 'if v'||ltrim(cnt)||' = 0 then '||
      'dbms_output.put_line(''alter table '||p_schema||'.'||r(i).table_name||
      ' modify ('||r(i).column_name||' not null);''); end if;'||chr(10);
    if cnt = r(i).colcount then
      str2 := str2 ||' from '||p_schema||'.'||r(i).table_name||';';
      str3 := str3 ||' end;';
      do_sql(str0||' '||str1||' '||str2||' '||str3);
    end if;
    prev := r(i).table_name;
    cnt := cnt + 1;
  end loop;
end;
/



If you want to see the underlying table scan queries that are being run, simply comment back in the “dbms_output.put_line” in the DO_SQL subroutine.

Enjoy!

Identity columns in 12c … just a sequence ?

Connor McDonald , , ,

This question came to me over Twitter, so I thought I’d whip out a quick post on it




Yes, we do implement the IDENTITY column via a sequence.  (Digression – I think this is a smart thing to do.  After all, we’ve had sequences for 20 years, so we know how they work, they are mature, tested, and rock solid, so why invent something new?)

So Peter’s question was – why not just do what we’ve always done and create a sequence and assign it as the default.  And yes, there is nothing wrong with doing that – it will work just fine.  But there are a couple of subtle differences between that and using the IDENTITY syntax.

1) The sequence is bound to the table, so when I drop the table, the sequence disappears as well


SQL> create table t ( x int generated as identity);

Table created.

SQL> select object_name from user_objects where created > sysdate - 60/86400;

OBJECT_NAME
----------------------------------------
T
ISEQ$$_195276

SQL> drop table t purge;

Table dropped.

SQL> select object_name from user_objects where created > sysdate - 60/86400;

no rows selected

2) You can lock down the column


SQL> create table t ( x int generated always as identity);

Table created.

SQL> insert into t values ( 12 ) ;
insert into t values ( 12 )
*
ERROR at line 1:
ORA-32795: cannot insert into a generated always identity column

Personally, I don’t have a preference.  The most important thing to me was that sequences can be used as a default value to avoid triggers on every single table.

Licensed for Advanced Compression? Don’t forget the network

Connor McDonald , , ,

We often think of Advanced Compression being exclusively about compressing data “at rest”, ie, on some sort of storage device.  And don’t get me wrong, if we consider just that part of Advanced Compression, that still covers a myriad of opportunities that could yield benefits for your databases and database applications:

  • Heat maps
  • Automatic Data Optimization
  • XML, JSON and LOB compression (including de-duplication)
  • Compression on backups
  • Compression on Data Pump files
  • Additional compression options on indexes and tables
  • Compressed Flashback Data Archive storage
  • Storage snapshot compression

However, if you are licensed for the option, there are other things that you can also take advantage of when it comes to compression of data on the network.

In 12c, Advanced Network Compression is part of the Advanced Compression option.  Obviously, the modern data centre typically co-locates application servers and database servers within a high speed high bandwidth network, but once data needs to be accessed over less optimal networks, for example, users running ad-hoc queries to their desktops, then compressing data across the wire can yield benefits.

Trust me, when you live in Perth, Western Australia, any kind of improvement to access data across the network is a good thing! Smile

Here’s an example of the option in action. Here’s my source table – which I’ve deliberately created with lots of potential for compression:


SQL create table comp_Test
  2  as select rownum x, rpad('x',1000,'x') y from dual
  3  connect by level <= 100000;

Table created.

Every row is almost a replica of the others, and column Y is 1000 repeated characters. So it is an artificial but perfect candidate to see the compression in action. To ensure that the network transmission of the data is a impactful factor here, I’ve located this table in a “database server” (my spare laptop) accessed via a slow wireless network from my other machine. We can see the impact of the network by starting with the default settings

Default settings


C:\temp>sqlplus scott/tiger@pdb122

SQL*Plus: Release 12.2.0.1.0 Production on Wed Dec 27 13:48:05 2017

Copyright (c) 1982, 2016, Oracle.  All rights reserved.

Last Successful login time: Wed Dec 27 2017 13:48:26 +08:00

Connected to:
Oracle Database 12c Enterprise Edition Release 12.2.0.1.0 - 64bit Production


SQL> set timing on
SQL> set arraysize 1000
SQL> set feedback only
SQL> select * from scott.comp_test;

100000 rows selected.

Elapsed: 00:00:24.68

So a touch more than 1000 bytes * 100000 rows yields the following session level statistics


SQL> @netstat

NAME                                                              VALUE
------------------------------------------------------------ ----------
bytes sent via SQL*Net to client                              102138497

Now I’ll activate compression by adding the following parameters to sqlnet.ora on client and server.


SQLNET.COMPRESSION=on
SQLNET.COMPRESSION_LEVELS=(low,high)
SQLNET.COMPRESSION_THRESHOLD=1024

and repeat the test in the a fresh connection. To see if we can potentially use compression, we can check V$SESSION_CONNECT_INFO


SQL> select sid, network_service_banner from V$SESSION_CONNECT_INFO
  2  where sid = sys_context('USERENV','SID')
  3  @pr
==============================
SID                           : 324
NETWORK_SERVICE_BANNER        : Windows NT TCP/IP NT Protocol Adapter for 64-bit Windows: Version 12.2.0.1.0 - Production
==============================
SID                           : 324
NETWORK_SERVICE_BANNER        : Oracle Advanced Network Compression Service for 64-bit Windows: Version 12.2.0.1.0 - Production
==============================
SID                           : 324
NETWORK_SERVICE_BANNER        : NTS Authentication service adapter for 64-bit Windows: Version 2.0.0.0.0 - Production
==============================
SID                           : 324
NETWORK_SERVICE_BANNER        : Encryption service for 64-bit Windows: Version 12.2.0.1.0 - Production
==============================
SID                           : 324
NETWORK_SERVICE_BANNER        : Crypto-checksumming service for 64-bit Windows: Version 12.2.0.1.0 - Production

or if you enable a SQL*Net trace, you’ll entries like this in the log files


nlstddp_dump_ptable:   SQLNET.COMPRESSION_LEVELS = HIGH
nlstddp_dump_ptable:   SQLNET.COMPRESSION = ON

Compression enabled


SQL> set timing on
SQL> set arraysize 1000
SQL> set feedback only
SQL> select * from scott.comp_test;

100000 rows selected.

Elapsed: 00:00:01.93

You can see the huge difference in elapsed time. Unfortunately, as far I can ascertain, the session network statistics are derived after decompression, because the bytes transferred still reflect the original sizes


SQL> @netstat

NAME                                                              VALUE
------------------------------------------------------------ ----------
bytes sent via SQL*Net to client                              102114310

We can also take advantage of the larger SDU sizes available in 12c. Now my sqlnet.ora looks like this:


DEFAULT_SDU_SIZE=1048576
SQLNET.COMPRESSION=on
SQLNET.COMPRESSION_LEVELS=(low,high)
SQLNET.COMPRESSION_THRESHOLD=1024

and then the test can be repeated.

Compression on, larger SDU


SQL> set timing on
SQL> set arraysize 1000
SQL> set feedback only
SQL> select * from scott.comp_test;

100000 rows selected.

Elapsed: 00:00:00.98

(* – elapsed times are averaged across a number of executions)

There is a whitepaper on Advanced Compression with more details here, so if you have the license, make sure you take a look to see if there are some benefits for you to maximize the return on your investment.

iASH–my “infinite ASH” routine

Connor McDonald , , , ,

I love Active Session History (ASH) data because a lot of the work I’ve done in my consulting life was “after the fact” diagnosis.  By this I mean that many of us have been in a similar circumstance where the customer will contact you not when a problem is occurring, but only when you contact them for some other potentially unrelated reason.  At which point you hear will that dreaded sentence:

“Yeah, the Order Entry screen was really slow a couple of hours ago”

And this is where ASH is an awesome resource.  With the ASH data available, there is a good chance you will be able to diagnose the issue without having to make an embarrassing request for the customer to repeat the task so that you can trace the underlying database activity.  Because no-one likes to be the person that says:

“Yeah that performance must have really sucked for you … Hey, let’s do it again!”

But even ASH has it’s limitations because sometimes the customer sentence is phrased slightly differently Smile

“Yeah, the Order Entry screen was really slow last Tuesday”

In this case, it is unlikely that the ASH data will still be available.  Whilst a subset of the invaluable ASH data is retained in DBA_HIST_ACTIVE_SESS_HISTORY, I would prefer to keep the complete set of ASH data available for longer than the timespan for which it is practical (due to the limitations of memory). So I wrote myself a simple little routine that keep all of the ASH data around for longer.  It’s hardly rocket science – just a little partitioned table to capture V$ACTIVE_SESSION_HISTORY at regular intervals.  Let’s walk through it so you can understand it and adapt it for your own use.

First I’ll create a partitioned table to hold the ASH data.  I’m using partitioning to avoid the need to index the table, so the insertion cost is minimal.  I’m partitioning by day and the code assumes this, so take care if you intend to modify it.


SQL> create table ash_hist
  2  partition by range (sample_time)
  3  interval( numtodsinterval(1,'day'))
  4  (partition p1 values less than (timestamp' 2017-01-01 00:00:00'))
  5  as select * from sys.gv_$active_session_history;

Table created.

Here is my procedure to capture the data.  The essentials of the routine are:

  • Starting with the most recent partition, find the last recorded entry in ASH_HIST.  We’ll look back up to 10 days to find our starting point (hence the daily partitions).
  • If there is no data for the last 10 days, we’ll bomb out, because we haven’t been running the routine frequently enough.
  • Copy all the ASH data from this point to now into ASH_HIST using a nice efficient INSERT-APPEND, but we’ll skip the session that is doing the copying. (You can include it if you want just by removing line 8)
  • Once per week (you can control this by tinkering with the IF conditions on line 34) we’ll drop the oldest partitions.  By default I keep 90 days, but you can set this by altering “l_retention” on line 5.

SQL>
SQL> CREATE OR REPLACE procedure save_ash_hist is
  2    l_hi_val_as_string varchar2(1000);
  3    l_hi_val_as_date   date;
  4    l_max_recorded     timestamp;
  5    l_retention        number := 90;
  6
  7  begin
  8    dbms_application_info.set_module('$$SAVE_ASH$$','');
  9    -- we are looping to take advantage
 10    -- of partition elimination
 11
 12    for i in 0 .. 10 loop
 13       select max(sample_time)
 14       into   l_max_recorded
 15       from   ash_hist
 16       where  sample_time > systimestamp - i;
 17
 18       exit when l_max_recorded is not null;
 19    end loop;
 20
 21    if l_max_recorded is null then
 22      raise_application_error(-20000,'No max sample time with 10 days');
 23    end if;
 24    dbms_output.put_line('Last copied time was '||l_max_recorded);
 25
 26    insert /*+ append */ into ash_hist
 27    select *
 28    from sys.gv_$active_session_history
 29    where sample_time > l_max_recorded
 30    and   ( module != '$$SAVE_ASH$$' or module is null );
 31    dbms_output.put_line('Copied '||sql%rowcount||' rows');
 32    commit;
 33
 34    if to_char(sysdate,'DYHH24') between 'TUE01' and 'TUE06' then
 35
 36      begin
 37        execute immediate 'alter table ash_hist set interval ()';
 38      exception
 39        when others then null;
 40      end;
 41      execute immediate 'alter table ash_hist set interval (NUMTODSINTERVAL(1,''DAY''))';
 42
 43      for i in ( select *
 44                 from   user_tab_partitions
 45                 where  table_name = 'ASH_HIST'
 46                 and    partition_position > 1
 47                 order by partition_position )
 48      loop
 49        l_hi_val_as_string := i.high_value;
 50        execute immediate 'select '||l_hi_val_as_string||' from dual' into l_hi_val_as_date;
 51
 52        if l_hi_val_as_date < sysdate - l_retention then
 53          execute immediate 'alter table ash_hist drop partition '||i.partition_name;
 54        else
 55          exit;
 56        end if;
 57
 58      end loop;
 59    end if;
 60  end;
 61  /

Procedure created.

And that is all there is to it.  Each time we run the procedure, we’ll grab all the ASH data since the last time we ran and keep it in ASH_HIST.


SQL>
SQL> select count(*) from ash_hist;

  COUNT(*)
----------
       792

1 row selected.


SQL>
SQL> exec save_ash_hist

PL/SQL procedure successfully completed.

SQL>
SQL> select count(*) from ash_hist;

  COUNT(*)
----------
       819

1 row selected.

A simple scheduler job to run the routine every couple of hours (I’m assuming your SGA holds at least 2 hours of samples in V$ACTIVE_SESSION_HISTORY – if not, you’d need to adjust the frequency) and you’re off and running.


SQL>
SQL>
SQL> BEGIN
  2      dbms_scheduler.create_job (
  3         job_name           =>  'ASH_CAPTURE',
  4         job_type           =>  'PLSQL_BLOCK',
  5         job_action         =>  'save_ash_hist;',
  6         start_date         =>  CAST((TRUNC(SYSDATE,'HH') + (1/24) + (55/24/60)) AS TIMESTAMP), -- job commences at 55 mins past the next hour
  7         repeat_interval    =>  'FREQ=HOURLY; INTERVAL=2',
  8         enabled            =>  true,
  9         comments           =>  'Permanent record of ASH data');
 10  END;
 11  /

PL/SQL procedure successfully completed.

You can assume all of the standard disclaimers here. Use at own risk, blah blah, no warranty, blah blah, etc

Addenda:  I should add that you could write this complete level of detail directly to DBA_HIST_ACTIVE_SESS_HISTORY via tinkering with “_ash_disk_filter_ratio” , but please get the endorsement of Support first.
