DDL for constraints – subtle things

The DBMS_METADATA package is very cool. I remember the days of either hand-crafting DDL statements based on queries to the data dictionary, or many a DBA will be familiar with running “imp show=y” or “imp indexfile=…” in order to then laboriously extract the DDL required from the import log file.  DBMS_METADATA removed all of those annoyances to give us a simple API to get the true and complete DDL for a database object.

But when extracting DDL from the database using the DBMS_METADATA package, you need to be aware of some subtleties especially if you plan on executing that DDL in the database.

Consider this example – I have a few tables and I want to extract the referential integrity constraints for one of them. Being a good cautious developer Smile I’ll just output the DDL first before attempt to do any execution of the statements:


SQL> create table tab1(id number, name varchar2(100),
  2                      constraint pk_tab1_id primary key(id));

Table created.

SQL> create table tab2(id number, name varchar2(100),
  2                      constraint pk_tab2_id primary key(id));

Table created.

SQL> create table tab3(id number, name varchar2(100), int_id number,
  2                      constraint pk_tab3_id primary key(id),
  3                      constraint fk_tab1_id foreign key(int_id) references tab1(id),
  4                      constraint fk_tab2_id foreign key(int_id) references tab2(id));

Table created.

SQL>
SQL> set serverout on
SQL> begin
  2    for i in (
  3      select t.table_name,
  4          dbms_metadata.get_dependent_ddl('REF_CONSTRAINT', table_name) ddl
  5      from   user_tables t
  6      where  table_name = 'TAB3'
  7      )
  8    loop
  9            dbms_output.put_line(i.ddl);
 10            --execute immediate i.ddl;
 11    end loop;
 12  end;
 13  /

  ALTER TABLE "MCDONAC"."TAB3" ADD CONSTRAINT "FK_TAB1_ID" FOREIGN KEY ("INT_ID") REFERENCES "MCDONAC"."TAB1" ("ID") ENABLE

ALTER TABLE "MCDONAC"."TAB3" ADD CONSTRAINT "FK_TAB2_ID" FOREIGN KEY ("INT_ID") REFERENCES "MCDONAC"."TAB2" ("ID") ENABLE

PL/SQL procedure successfully completed.

That all looks fine – I have my two ALTER statements ready to go.  So now I’ll comment back in the ‘execute immediate’ command and all should be fine.


SQL> set serverout on
SQL> begin
  2    for i in (
  3      select t.table_name,
  4             dbms_metadata.get_dependent_ddl('REF_CONSTRAINT', table_name) ddl
  5      from   user_tables t
  6      where  table_name = 'TAB3'
  7      )
  8    loop
  9            dbms_output.put_line(i.ddl);
 10            execute immediate i.ddl;
 11    end loop;
 12  end;
 13  /

  ALTER TABLE "MCDONAC"."TAB3" ADD CONSTRAINT "FK_TAB1_ID" FOREIGN KEY ("INT_ID") REFERENCES "MCDONAC"."TAB1" ("ID") ENABLE

ALTER TABLE "MCDONAC"."TAB3" ADD CONSTRAINT "FK_TAB2_ID" FOREIGN KEY ("INT_ID") REFERENCES "MCDONAC"."TAB2" ("ID") ENABLE
begin
*
ERROR at line 1:
ORA-01735: invalid ALTER TABLE option
ORA-06512: at line 10
ORA-06512: at line 10

The seems an odd result. Since in this simple example I’m just running the commands straight back into the same database, I might have expected a “Constraint already exists”, or “Object name exists” style of error, but this is different. This error is telling that the statement is invalid – which obviously should not be the case if it came straight out of DBMS_METADATA. But a simple amendment to my anonymous block will reveal the answer. I will output a line of dashes each time I cycle through the cursor loop



SQL> set serverout on
SQL> begin
  2    for i in (
  3      select t.table_name,
  4             dbms_metadata.get_dependent_ddl('REF_CONSTRAINT', table_name) ddl
  5      from   user_tables t
  6      where  table_name = 'TAB3'
  7      )
  8    loop
  9            dbms_output.put_line('========================================');
 10            dbms_output.put_line(i.ddl);
 11            --execute immediate i.ddl;
 12    end loop;
 13  end;
 14  /
========================================

  ALTER TABLE "MCDONAC"."TAB3" ADD CONSTRAINT "FK_TAB1_ID" FOREIGN KEY ("INT_ID") REFERENCES "MCDONAC"."TAB1" ("ID") ENABLE

ALTER TABLE "MCDONAC"."TAB3" ADD CONSTRAINT "FK_TAB2_ID" FOREIGN KEY ("INT_ID") REFERENCES "MCDONAC"."TAB2" ("ID") ENABLE

PL/SQL procedure successfully completed.

And therein lies the issue. I got two ALTER commands back on screen, but in reality they both came back from a single row fetched from the cursor. The ALTER commands were separated by a carriage return, but if I try to execute that single row, then the statement is invalid because it is an attempt to run two ALTER commands in a single statement. The output looks like two rows from the cursor but it was not.

That is a problem if I want to store that DDL in a table or a file, because I can’t use it as it currently stands, and I don’t want to have to write some scripts to parse that DDL to add semi-colons or split it into multiple commands, because one of the motivations for DBMS_METADATA in the first place was to avoid all that irritation.

There is an easy fix to this. Rather than getting the dependent DDL for a table, we can get the “direct” DDL for the constraints themselves.  In this way, you’ll get a row from the cursor for each constraint, and hence one DDL statement per constraint as well.



SQL> set serverout on
SQL> begin
  2    for i in (
  3         select t.table_name,
  4                dbms_metadata.get_ddl('REF_CONSTRAINT', constraint_name) ddl
  5         from user_constraints t
  6         where table_name = 'TAB3'
  7         and constraint_type = 'R'
  8      )
  9    loop
 10            dbms_output.put_line('========================================');
 11            dbms_output.put_line(i.ddl);
 12            --execute immediate i.ddl;
 13    end loop;
 14  end;
 15  /
========================================

  ALTER TABLE "MCDONAC"."TAB3" ADD CONSTRAINT "FK_TAB1_ID" FOREIGN KEY ("INT_ID") REFERENCES "MCDONAC"."TAB1" ("ID") ENABLE
========================================

  ALTER TABLE "MCDONAC"."TAB3" ADD CONSTRAINT "FK_TAB2_ID" FOREIGN KEY ("INT_ID") REFERENCES "MCDONAC"."TAB2" ("ID") ENABLE

PL/SQL procedure successfully completed.

Parsing freeform data in flat files

SQL loader is a very cool utility that has existed for a long time within Oracle to load flat files into the database. However sometimes people find the control file syntax quite cryptic, and when it comes to passing very complicated structures, this can mean control files which are hard to maintain. For me the best solution here is to use an external table. That way we can combine the power of the SQL Loader control file syntax embedded within the external table definition, along with the full power of PL/SQL and SQL for additional parsing of that data.

Here is an example where the data is spread across multiple lines and the task is to bring all that data together into a natural form, namely an ID followed by text.

So here is my file that has free format text


10,some data
that is really
annoying because it
spans lots of rows.
20,and some more than does not.
30,and a mixture of stuff and we
will assume that numerics then comm as
is the thing that tells us it is a new line.
40,otherwise we will keep on going.

What I’m going to do is use an external table to bring that data in as it is within the file, and then use a PL/SQL function in pipelined mode to parse the data into the component attributes.


SQL>
SQL> create table freeform
  2  (
  3  line varchar2(200)
  4  )
  5  ORGANIZATION external
  6  (
  7  TYPE oracle_loader
  8  DEFAULT DIRECTORY temp
  9  ACCESS PARAMETERS
 10  (
 11  RECORDS DELIMITED BY NEWLINE
 12  FIELDS LDRTRIM
 13  (
 14  line char(200)
 15  )
 16  )
 17  location
 18  (
 19  'freeform.dat'
 20  )
 21  )REJECT LIMIT UNLIMITED ;

Table created.

SQL>
SQL> select * from freeform;

LINE
--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
10,some data
that is really
annoying because it
spans lots of rows.
20,and some more than does not.
30,and a mixture of stuff and we
will assume that numerics then comm as
is the thing that tells us it is a new line.
40,otherwise we will keep on going.

9 rows selected.

SQL>
SQL> create or replace
  2  type output_data as object (id int, str varchar2(500))
  3  /

Type created.

SQL>
SQL> create or replace
  2  type output_list as table of output_data
  3  /

Type created.

SQL>
SQL> create or replace
  2  function cleanup_that_sucker(rc sys_refcursor) return output_list pipelined is
  3    type strlist is table of varchar2(200) index by pls_integer;
  4    s strlist;
  5    o output_data := output_data(null,null);
  6    c pls_integer := 0;
  7  begin
  8    loop
  9      fetch rc bulk collect into s limit 500;
 10
 11      for i in 1 .. s.count loop
 12        c := c + 1;
 13        if regexp_like(s(i),'^[[:digit:]]+,') then
 14          if c > 1 then
 15             pipe row (o);
 16          end if;
 17          o.id  := substr(s(i),1,instr(s(i),',')-1);
 18          o.str := substr(s(i),instr(s(i),',')+1);
 19        else
 20          o.str := o.str || ' ' || s(i);
 21        end if;
 22      end loop;
 23      exit when rc%notfound;
 24    end loop;
 25    pipe row (o);
 26    return;
 27  end;
 28  /

Function created.

SQL> sho err
No errors.
SQL>
SQL> select *
  2  from cleanup_that_sucker(cursor(
  3          select line from freeform
  4          ));

        ID STR
---------- ------------------------------------------------------------------------------------------------------------------------
        10 some data that is really annoying because it spans lots of rows.
        20 and some more than does not.
        30 and a mixture of stuff and we will assume that numerics then comm as is the thing that tells us it is a new line.
        40 otherwise we will keep on going.

4 rows selected.

SQL>
SQL>

And there we have it. We have the full power of PL/SQL and SQL at our fingertips even though we are parsing flat file data. This avoids complicated control file syntax and makes ongoing maintenance far easier. Performance is still good because we are using the bulk collect feature in PL/SQL. Also because we are taking a cursor expression as input, we have lots of flexibility in terms of what data are we passing in. We simply change the SQL expression in the cursor.

LOBs and tiny typos

This one caught me out – I was racing around looking for bugs, or parameter files, or hidden settings that stopped SECUREFILE lobs from being created.  Here was my incredibly simple test case – create a securefile LOB, and then make sure it’s a securefile.


SQL> create table t1 ( b blob ) lob ( b ) store as securfile;

Table created.

SQL> select securefile
  2  from   user_lobs
  3  where  table_name = 'T1';

SEC
---
NO

That had me bamboozled, but it is a trivial explanation.  Notice that I did not spell  “SECUREFILE” correctly.  As a result, the syntax is interpreted as being the name of the LOB segment in the data dictionary, rather than the specification of how the LOB should be stored.


SQL> select segment_name
  2  from   user_lobs
  3  where  table_name = 'T1';

SEGMENT_NAME
------------------------------
SECURFILE

All it takes is the correct “e” in “securefile” and normal service was resumed Smile


SQL> drop table t1 purge;

Table dropped.

SQL> create table t1 ( b blob ) lob ( b ) store as securefile;

Table created.

SQL> select securefile
  2  from   user_lobs
  3  where  table_name = 'T1';

SEC
---
YES

So why blog about it such a silly mistake ?  Because this is a common issue with all of us as developers.  We see something unusual and our first assumption is that it must be some fundamental flaw in the product we’re using.  That mindset has been around as long computer programming has existed, but but 20 years ago, it wasn’t so easy to make a fool of yourself by bleating about it on social media Smile.  I remember when I first started programming, one of my mentors told me: “Remember, the COBOL compiler is not broken”, and of course, we can insert any programming language into that sentence.  So before you jump on to Twitter … just take a moment to re-check that script, or get a colleague to give it a “once over”.  You’ll either save yourself some embarrassment, or you add additional rigour to your test case – it’s win-win.

Please keep your foreign keys

I came across an interesting blog post the other day about whether databases should be (declaratively) enforcing the foreign key relationships between tables.  The blog post discussed the issue of foreign keys being temporarily disabled to perform data loading, and then encountering the problem of what to do when those foreign keys cannot be re-enabled due to bad data.  Perhaps they should just be omitted altogether ?  I don’t want to put words in the author’s mouth, because he stressed he was not taking sides in the “should we” or “shouldn’t we” debate on declarative foreign keys, but the concluding part of the blog was:


I find that is a bit like saying:

“Well, seat belts are compulsory but people are still getting injured in car accidents, so you may as well just not bother with seat belts at all”

So here’s some information from the other perspective – why constraints are so important for your database in terms of both data correctness and performance.

Firstly here is an AskTOM magazine article that demonstrates the benefits of declarative constraints to both the optimizer, and to the availability of technologies such as materialized view rewrite.

Also, to respond to the particular topic in the blog post about handling data loads, here is a video from the Real World Performance group about how you can validate massive sets of data for referential integrity, and then still apply the constraints efficiently to give the optimizer all those benefits for subsequent query processing.

But if all of that seems to complicated to read and digest, perhaps an easier way of understanding the importance of constraints is to watch my simple video about Australian wildlife Smile

Better to be safe than sorry…

I’ve always been worried about taking a script that is fine to run in my non-production environments (in particular a DROP script) and accidentally running it in a Production environment, shortly followed by the typing up of a fresh resume to look for a new job once the mistake is discovered Smile

The standard means of a “least privilege required” model when it comes to Production access is a good step along this road to protecting the database. But ultimately, at one time or another, an administrator with appropriate privileges, good intentions, but (say) bad cut-paste skills might inadvertently run a drop command against a database they did not want to.  (A well publicised example of this happened quite recently https://www.theregister.co.uk/2017/02/01/gitlab_data_loss/)

So it would be nice to have a method of adding a ‘double check’ facility so that we can guard against a DROP being run on your production system inadvertently. That way, even if you did  run that drop script against Production, you would be “saved from yourself”. Here’s one such possible means you might want to consider. We’ll use a context variable that has to be set in order for DROP commands to be processed.


--
-- Our context
--
SQL> create context DDL_CHECK using ddl_checker;

Context created.

--
-- A routinte to set it
--
SQL> create or replace
  2  procedure ddl_checker(p_val varchar2) is
  3  begin
  4    dbms_session.set_context('DDL_CHECK','ENABLED',p_val);
  5  end;
  6  /

Procedure created.

--
-- If we are on the Production database, DROP DDL's only proceed is the context variable is set
--
SQL> create or replace
  2  trigger ddl_checker_before
  3  before drop on scott.schema
  4  begin
  5    if sys.database_name like '%PROD%' and sys_context('DDL_CHECK','ENABLED') is null
  6    then
  7      raise_application_error(-20000,'DDL confirmation context is not set');
  8    end if;
  9  end;
 10  /

Trigger created.

--
-- And after every DROP, the context is reset for the next use so it cannot be left on inadvertently
--
SQL> create or replace
  2  trigger ddl_checker_after
  3  after drop on scott.schema
  4  begin
  5    ddl_checker(null);
  6  end;
  7  /

Trigger created.

SQL>
SQL>
SQL> grant execute on ddl_checker to scott;

Grant succeeded.

SQL>

So now we can see what happens when SCOTT attempts some DDL in Production by mistake.


SQL> conn scott/tiger
Connected.

SQL> drop table t purge;
drop table t purge
*
ERROR at line 1:
ORA-00604: error occurred at recursive SQL level 1
ORA-20000: DDL confirmation context is not set
ORA-06512: at line 4

--
-- We must explicitly express our intention to perform a DDL
--
SQL> exec admin.ddl_checker('true')

PL/SQL procedure successfully completed.

--
-- and only then are we allowed to run a DROP command
--
SQL> drop table t purge;

Table dropped.

--
-- and in doing so, we don't have any lingering access
--
SQL> drop table t1 purge;
drop table t1 purge
*
ERROR at line 1:
ORA-00604: error occurred at recursive SQL level 1
ORA-20000: DDL confirmation context is not set
ORA-06512: at line 4


SQL>

I stress – this is not about securing administrator access or replacing your existing processes for auditing or locking down the privileges on your production systems. This is just about that extra check to help your over-worked and/or over-tired administrators from committing a small mistake that becomes a catastrophic error.

DDL triggers – interesting results

This question came in on AskTom, yielding a very interesting result when it comes to DDL triggers. To set the scene, I’ll first create a table called T which is just a copy of SCOTT.EMP


SQL> create table scott.t as select * from scott.emp;

Table created.

SQL> desc scott.t
 Name                                                              Null?    Type
 ----------------------------------------------------------------- -------- -----------------
 EMPNO                                                             NOT NULL NUMBER(4)
 ENAME                                                                      VARCHAR2(10)
 JOB                                                                        VARCHAR2(9)
 MGR                                                                        NUMBER(4)
 HIREDATE                                                                   DATE
 SAL                                                                        NUMBER(7,2)
 COMM                                                                       NUMBER(7,2)
 DEPTNO                                                                     NUMBER(2)

Now let’s say our requirement is to capture anything that relates to columns for tables in the SCOTT schema. So if we create a table, then we want to see all of those columns, and also, if we alter an existing table, then we want to see what the table looks like as a result after the columns have been added or dropped. So let’s build a simple DDL trigger to do that. First, I’ll create a procedure which will list all of the columns for any table name that we pass it.  We’ll work exclusively in SCOTT for this example.


SQL> create or replace
  2  procedure create_audit_trigger(p_tab varchar2) is
  3  begin
  4    for i in ( select column_name from dba_tab_columns
  5               where table_name = p_tab
  6               and owner = 'SCOTT'
  7             )
  8    loop
  9      dbms_output.put_line(i.column_name);
 10    end loop;
 11  end;
 12  /

Procedure created.

And we’ll give it a quick test so make sure it works


SQL> set serverout on
SQL> exec create_audit_trigger('EMP')
EMPNO
ENAME
JOB
MGR
HIREDATE
SAL
COMM
DEPTNO

PL/SQL procedure successfully completed.

We’ll now put that inside our DDL trigger any time we perform an ALTER or CREATE DDL operation on a table.


SQL> create or replace
  2  TRIGGER audit_trigger_update
  3  AFTER ALTER OR CREATE ON scott.SCHEMA
  4  WHEN (ORA_DICT_OBJ_TYPE = 'TABLE')
  5  BEGIN
  6    create_audit_trigger(ORA_DICT_OBJ_NAME);
  7  END;
  8  /

Trigger created.

SQL> conn scott/tiger
Connected.

Now we’ll create a table and see if it works.


SQL> set serverout on
SQL> create table t1 ( x int, y int );
X
Y

Table created.

And we’ll drop a column to test that


SQL> alter table t1 drop column y;
X

So far so good. Now let us add a column to the table.


SQL> alter table t add x int;
EMPNO
ENAME
JOB
MGR
HIREDATE
SAL
COMM
DEPTNO  -- ???? no X

Table altered.

This is an unexpected result. At the time within the trigger we query the data dictionary to obtain a list of columns, it does not yet appear in the definition. Now that the statement has completed, if we perform a describe on the table, we can see that the new column X is indeed there.


SQL> desc t
 Name                                                                    Null?    Type
 ----------------------------------------------------------------------- -------- --------------
 EMPNO                                                                   NOT NULL NUMBER(4)
 ENAME                                                                            VARCHAR2(10)
 JOB                                                                              VARCHAR2(9)
 MGR                                                                              NUMBER(4)
 HIREDATE                                                                         DATE
 SAL                                                                              NUMBER(7,2)
 COMM                                                                             NUMBER(7,2)
 DEPTNO                                                                           NUMBER(2)
 X                                                                                NUMBER(38)

The only workaround I can currently think of is to do work asynchronously, via DBMS_JOB. Rather than DBMS_OUTPUT, I’ll log the column names in a table so we can view them after the fact:


SQL> create table col_debug ( ts timestamp, col_name varchar2(50));

Table created.

SQL> create or replace
  2  procedure create_audit_trigger(p_tab varchar2) is
  3    l_now timestamp := systimestamp;
  4  begin
  5    for i in ( select column_name from dba_tab_columns
  6               where table_name = p_tab
  7               and owner = 'SCOTT'
  8             )
  9    loop
 10      insert into col_debug values (l_now,i.column_name);
 11    end loop;
 12    commit;
 13  end;
 14  /

Procedure created.

SQL> create or replace
  2  TRIGGER audit_trigger_update
  3  AFTER ALTER OR CREATE ON scott.SCHEMA
  4  WHEN (ORA_DICT_OBJ_TYPE = 'TABLE')
  5  declare
  6    j int;
  7  BEGIN
  8    dbms_job.submit(j,'create_audit_trigger('''||ORA_DICT_OBJ_NAME||''');');
  9  END;
 10  /

Trigger created.

Now I repeat the addition of a column, and the check out debugging table


SQL> alter table t add x1 int;

Table altered.

SQL> select * from col_debug;

TS                                                                          COL_NAME
--------------------------------------------------------------------------- ---------------
24-FEB-17 03.02.36.553000 PM                                                EMPNO
24-FEB-17 03.02.36.553000 PM                                                ENAME
24-FEB-17 03.02.36.553000 PM                                                JOB
24-FEB-17 03.02.36.553000 PM                                                MGR
24-FEB-17 03.02.36.553000 PM                                                HIREDATE
24-FEB-17 03.02.36.553000 PM                                                SAL
24-FEB-17 03.02.36.553000 PM                                                COMM
24-FEB-17 03.02.36.553000 PM                                                DEPTNO
24-FEB-17 03.02.36.553000 PM                                                X
24-FEB-17 03.02.36.553000 PM                                                X1

10 rows selected.

So the trigger submits a job rather than does the work itself.

Why does an ADD column operation behave differently to DROP and CREATE? That remains a mystery Smile




Duplicate constraints are impossible right ?

Here’s a very simple example of a table called PARENT being a (surprise surprise) parent in a referential integrity relationship to a (drum roll for my choice of name) CHILD table


SQL> create table parent ( p int, constraint PAR_PK primary key (p) );

Table created.

SQL> create table child ( c int,
  2        p int
  3      );

Table created.

SQL> alter table child add constraint fk1 foreign key ( p ) references parent ( p );

Table altered.

That is all as we would expect, and similarly, if I inadvertently try to add the same foreign key constraint, I’ll get an error


SQL> alter table child add constraint fk2 foreign key ( p ) references parent ( p );
alter table child add constraint fk2 foreign key ( p ) references parent ( p )
                                     *
ERROR at line 1:
ORA-02275: such a referential constraint already exists in the table

So you might be wondering, how on earth did I get myself into the following calamity on my database:


SQL> select c.constraint_name, cc.column_name, c.r_constraint_name
  2  from   user_constraints c,
  3         user_cons_columns cc
  4  where  c.table_name = 'CHILD'
  5  and    c.constraint_type = 'R'
  6  and    c.constraint_name = cc.constraint_name;

CONSTRAINT_NAME                COLUMN_NAME                    R_CONSTRAINT_NAME
------------------------------ ------------------------------ --------------------
FK1                            P                              PAR_PK
FK2                            P                              PAR_PK

Yes – thats TWO foreign key constraints implementing the identical check.  How did I bypass the duplicate check we saw above ?

It’s just a little idiosyncrasy in all versions of Oracle since the inception of foreign key constraints. If you specify the constraints as part of the table creation DDL, the check for duplicates is skipped.


SQL> create table child ( c int,
  2    p int,
  3    constraint fk1 foreign key ( p ) references parent ( p ) ,
  4    constraint fk2 foreign key ( p ) references parent ( p )
  5  );

Table created.

It is worth looking for and rectifying this condition on your databases, because it can lead to confusing errors, for example, when you do a datapump of such a schema – the import will (correctly) fail on the second constraint, but you’ll be scratching your head when you go look at the imported result and see that the constraint is there !

This is fixed in 12c onwards.


SQL> create table child ( c int,
  2    p int,
  3    constraint fk1 foreign key ( p ) references parent ( p ) ,
  4    constraint fk2 foreign key ( p ) references parent ( p )
  5  );
  constraint fk2 foreign key ( p ) references parent ( p )
                 *
ERROR at line 4:
ORA-02274: duplicate referential constraint specifications
